Plastic Extrusion Three Roll Calender Machine With Surface Hardness 68~72hs

Plastic Extrusion Three Roll Calender Machine With Surface Hardness 68~72hs

MOQ: One set
Price: $16000-$17000
Standard Packaging: wooden box
Delivery Period: 90days
Payment Method: T/T
Supply Capacity: 180-200 sets per year
Detail Information
Place of Origin
China
Brand Name
MINGDI
Certification
CE, ISO
Model Number
XLG-1100×2000
Condition:
New
Voltage:
380V
Weight:
20 Tons
Warranty:
1 Year
Automatic Grade:
Automatic
Material:
Rubber,PU Or Rubber Available
Minimum Order Quantity:
One set
Price:
$16000-$17000
Packaging Details:
wooden box
Delivery Time:
90days
Payment Terms:
T/T
Supply Ability:
180-200 sets per year
Highlight:

72hs Hardness Three Roll Calender

,

Plastic Extrusion 3 Roll Calender

,

Plastic Extrusion Roll Calender Machine

Product Description

XLG-1100×2000 Plastic extrusion Three-roller calender







Features:


1. Rolls: chilled alloy cast iron rolls with surface hardness 68~72hs. the rolls are mirror finished & polished, duly grinding and are hollowed for cooling or heating.


2. Roll clearance adjusting unit: nip adjustment at two roller ends is done manually using two separate screws attached to the brass housing body.


3. Roll cooling: universal rotary joints with inner spray pipes with hoses and headers. piping is complete up to supply pipe terminal.


4. Journal bearing housing: heavy duty steel casting housing fitted with anti friction roller bearings.


5. Lubrication: full automatic grease lubrication pump for anti friction roller bearings fitted in dust sealed housing.


6. Stand frame & apron: heavy duty steel casting.


7. Gearbox: hard-tooth reduction gearbox, GUOMAO brand.


8. Base frame: common base frame heavy duty, steel channel and ms plate fabricated accurately machined on which whole machine with gearbox and motor are fitted.


9. Electric panel: star delta electric operating panel with auto reversing, voltmeter, ampere, overload protection relay, 3 phase indicator and emergency stop switch.



Plastic Extrusion Three Roll Calender Machine With Surface Hardness 68~72hs 0Plastic Extrusion Three Roll Calender Machine With Surface Hardness 68~72hs 1
